Hot Rolled Steel Frame Buildings Portable Steel Structure Garage
Product Description
Steel structure buildings, also referred to as steel frame buildings or steel construction buildings, are architectural structures primarily constructed using steel as the primary structural material. These buildings provide a multitude of benefits compared to traditional construction methods, making them highly favored across various applications.
Here are some key advantages of steel structure buildings:
(1)Cost-Effectiveness: Steel structure buildings offer cost advantages in terms of construction and maintenance. The standardized design and efficient manufacturing processes reduce material waste and labor costs. Steel structures also require minimal maintenance, resulting in long-term cost savings.
(2)Sustainability: Steel is a highly recyclable material, making steel structure buildings an environmentally sustainable choice. Steel components can be recycled at the end of a building's life cycle, reducing waste and promoting resource conservation.
(3)Expansion and Adaptability: Steel structures allow for easy expansion or modification of buildings as needs change. The modular nature of steel components enables straightforward alterations without significant disruption to operations.
Main structure: Welded H-shaped steel
Purlin: C-shaped cross-section channel or Z-shaped cross-section channel
Roof cladding: sandwich panel or corrugated steel plate and glass fiber coil
Wall cladding: sandwich panel or corrugated steel plate
Tie rod: round steel tube
Bracket: round rod
Pillar support, horizontal support: angle steel, H-shaped steel or steel pipe
Knee pads: angle steel
Roof: Corrugated steel plate
Coating layer: color steel plate
Gutter: color steel plate
Rain mouth: PVC pipe
Door: sliding sandwich panel or metal
Window: PVC or aluminum window
Connection: high-strength bolts
Item | Material | Description and surface process | |
Main steel frame | Column and Beam | Q235 or Q345 | H section steel with two coats of mid-gray paint |
| Purlin | Q235 or Q345 | Galvanizd C or Z type steel |
Connecting
Pieces | Tie tube | Q235 | Circular Tube with two coats of mid-gray paint |
| Knee-Bracing | Q235 | L50*4 Galvanizd angle steel |
| Strutting piece | Q235 | φ12*2.5 Galvanizd Circular Tube |
| Column Bracing | Q235 | Circular Tube with two coats of mid-gray paint |
| Horizontal Bracing | Q235 | Circular Tube with two coats of mid-gray paint |
| Casing | Q235 | φ30*2.5 Galvanized Circular Tube |
Door and Window | Item | Description |
| Door | Roller shutter door or Sliding door |
| Window | PVC Window or aluminum alloy window |
Other parts | Ventilating device | Fan,Ventilation window |
| Bolt | Foundation bolt,High strengthen bolt, Normal bolts |
| Skylight | Yx-840 Glass Fiber Reinforced Plastics |
| Out/Inner ridge tile | 0.50mm Color sheet |
| Crane beam | Q235 or Q345 H section steel with two coats of mid-gray paint |
